Welcome to CoolingTowerTechnology.com from Whaley Products, Inc. WPI has been in business since 1993 and has established itself as a leader in cooling system design and manufacturing. The purpose of this site is to provide our customers with all of their cooling tower supplies needs. If you are interested in a chiller system, or any other fluid cooling system design, you can visit our sister site at WaterChillingProducts.com for assistance. If you are in need of water chilling parts,(such as heat exchangers, compressors, pumps…etc), you can visit WaterChillingSupply.com for more information.

Specifications and Pricing*Click on tower model number for pricing*

Model

Nominal Tons / KW

Flow: GPM

Description

Basin Volume (gal)

Pump Tank Vol. (Optional)

Unit Weight (lbs)

Fan Motor HP/RPM

Fan Motor Max Noise

FLA 208-230/3, 460/3

Nominal Air Flow (CFM)

Height (A)

4″ C-Channel Frame Dimensions

650-10

10 Ton/ 44KW

30 GPM

1ea 10 Ton Cell

25 gal

100 gal

300 lbs

1/2HP – 1725RPM

61 dB

2, 1

3,000 CFM

78″

Frame Optional

650-15

15 Ton/ 66KW

45 GPM

1ea 15 Ton Cell

25 gal

100 gal

300 lbs

1/2HP – 1725RPM

61 dB

2, 1

3,250 CFM

78″

Frame Optional

850-20

20 Ton/ 88KW

60 GPM

1ea 20 Ton Cell

44 gal

150 gal

400 lbs

3/4HP – 1140RPM

47 dB

3.3 – 3, 1.5

6,000 CFM

84″

Frame Optional

850-25

25 Ton/ 110KW

75 GPM

1ea 25 Ton Cell

44 gal

150 gal

400 lbs

3/4HP – 1140RPM

47 dB

3.3 – 3, 1.5

6,500 CFM

84″

Frame Optional

1250-30

30 Ton/ 132KW

90 GPM

1ea 30 Ton Cell

100 gal

305 gal

630 lbs

2HP – 1140RPM

57 dB

6.7 – 6.6, 3.3

11,300 CFM

102″

48″x48″

1250-40

40 Ton/ 176KW

120 GPM

1ea 40 Ton Cell

100 gal

305 gal

630 lbs

2HP – 1140RPM

57 dB

6.7 – 6.6, 3.3

12,000 CFM

102″

48″x48″

1550-50

50 Ton/ 220KW

150 GPM

1ea 50 Ton Cell

150 gal

500 gal

911 lbs

3HP – 1155RPM

61 dB

10.4 – 9.6, 4.8

15,000 CFM

113″

60″x60″

1550-75

75 Ton/ 330KW

225 GPM

1ea 75 Ton Cell

150 gal

500 gal

911 lbs

3HP – 1155RPM

61 dB

10.4 – 9.6, 4.8

17,500 CFM

113″

60″x60″

1850-100

100 Ton/ 440KW

300 GPM

1ea 100 Ton Cell

224 gal

1000 gal

1186 lbs

5HP – 1150RPM

61 dB

16.5 – 15.2, 7.6

20,500 CFM

122″

72″x72″

1850-125

125 Ton/ 550KW

375 GPM

1ea 125 Ton Cell

224 gal

1000 gal

1186 lbs

5HP – 1150RPM

61 dB

16.5 – 15.2, 7.6

22,700 CFM

122″

72″x72″

2-1850-200

200 Ton/ 880KW

600 GPM

2ea 100 Ton Cells

448 gal

1550 gal

2x1186lbs

2ea. 5HP – 1150RPM

2ea 61dB

33-30.4, 15.2

41,000 CFM

122″

2ea 72″x72″

2-1850-250

250 Ton/ 1100KW

750 GPM

2ea 125 Ton Cells

448 gal

1550 gal

2x1186lbs

2ea. 5HP – 1150RPM

2ea 61dB

33-30.4, 15.2

45,400 CFM

122″

2ea 72″x72″

3-1850-300

300 Ton/ 1320KW

900 GPM

3ea 100 Ton Cells

672 gal

2100 gal

3x1186lbs

3ea. 5HP – 1150RPM

3ea 61dB

49.5-45.6, 22.8

61,500 CFM

122″

3ea 72″x72″

3-1850-375

375 Ton/ 1650KW

1125 GPM

3ea 125 Ton Cells

672 gal

2100 gal

3x1186lbs

3ea. 5HP – 1150RPM

3ea 61dB

49.5-45.6, 22.8

68,100 CFM

122″

3ea 72″x72″

4-1850-400

400 Ton/ 1760KW

1200 GPM

4ea 100 Ton Cells

896 gal

2500 gal

4x1186lbs

4ea. 5HP – 1150RPM

4ea 61dB

66-60.8, 30.4

82,000 CFM

122″

4ea 72″x72″

4-1850-500

500 Ton/ 2200KW

1500 GPM

4ea 125 Ton Cells

896 gal

3000 gal

4x1186lbs

4ea. 5HP – 1150RPM

4ea 61dB

66-60.8, 30.4

90,800 CFM

122″

4ea 72″x72″

UNIT CAPACITY RATING:
3 GPM / ton from 95°F to 85°F (at 78°F wet bulb).

Cooling Towers Available

Cooling Tower Model	Tower Sizing
10-15 Ton Cooling Towers	10 Ton 15 Ton
20-25 Ton Cooling Towers	20 Ton 25 Ton
30-40 Ton Cooling Towers	30 Ton 40 Ton
50-75 Ton Cooling Towers	50 Ton 55 Ton 60 Ton 65 Ton 70 Ton 75 Ton
100-125 Ton Cooling Towers	100 Ton 110 Ton 115 Ton 120 Ton 125 Ton
Multi-Cell Cooling Towers	150 Ton 200 Ton 250 Ton 300 Ton 400 Ton 500 Ton 600 Ton 700 Ton 800 Ton 900 Ton 1000 Ton
Closed Loop Evaporative Cooling	10 to 1000 Tons
Cooling Tower Parts & Accessories	100 Ton 110 Ton 115 Ton 120 Ton 125 Ton
